3. Multiplication of two numbers using Labview

Hi in this article learn how to Multiplication two numerical
numbers using labview coding...


Step 1:  Open labview software..

Step 2:  Open blank VI..

Step 3: Use block diagram panel to program

Step 4:  Use Right click to get codes

Step 5: Follow Right click-Numeric-Multiply

Step 6:  Place the Multiply tool where we want

Step 7:  Then Right click at node of input to Multiplication tool

Step 8: Create Control at enter input

Step 9: Now create indicator by using right click at the output node at multiplication pin

Step 10: Check weather the program is correct or wrong

Step 11: Run continuously if program is correct otherwise check the program

Step 12: Use Front panel to RUN...

Step 13: Enter inputs in the front panel

Step 14:  Now get the results...

Watch video:
